Shandong Group Co.,Ltd.

Four side planer MB3006,MB4006;
Working width range (mm): 20-230
Working height range (mm):6-150
Number of spindles (min-max):5-10
Spindle speed (rpm):6000
Frequency controlled feed speed: 5-35m/min; (MB4006'S SPEED 5-60M/MIN)
Min-Max cutting circle of the horizontal (except 1st bottom 180mm):110-200;
Min-Max cutting circle of the vertical spindles (mm):110-200
Spindle diameter (mm):40
Adjustment range for in feed bed plate and fence (mm):10
Axial movement for horizontal and vertical spindles (mm):22 Feed rolls diameter (mm):140
In feed table length (mm):2000
Right vertical spindle (HP):7.5
Left vertical spindle (HP):7.5
Top horizontal spindle (HP):10 2nd
Bottom horizontal spindle (HP):7.5
Beam adjustment (HP):2.0
Increased spindle speed up to (rpm):8000

Product Feature
Chromed bed plates and guides for work with abrasive materials,such MDF.
Strong infeed chipbreakers and outfeed hold-down regulation by just turning a screw.
