     Fujian ubest shuttering panel factroy

     About this company : We are the first, biggest and the most professional supplier of wood products for concrete formwork and scaffolding here in South China.We mainly export plywood, three ply shuttering panel, formwork H20 beam, 3 ply shuttering panel, three layers shuttering panel, triply shuttering panel, H20 Timber Beam (Wood Girder), Formwork wooden H20 beam, Laminated Veneer Lumber, film faced plywood, Shuttering Plywood, concrete melamine board, Pine Plywood, MDF (medium density fibreboard), particle board, Softwood Scaffold Panel (Pine LVL scaffolding Plank), 3 ply decoration board, etc. Our products meet E1/E2 Standard. We are one of the most professional supplier for three ply shuttering panels and H20 timber beam, especially, we are expert on 3 ply shuttering panels and H20 beam, our three ply shuttering panels and wooden H20 beam product passed many tested by authority and our customers, and we exported our three ply shuttering panels and formwork H20 timber beam to more than 40 countries, including Europe, Middle East, Africa and Asia. We are the first supplier can produce in large scale at present in China.

     Contact : Christina Zhou, saleperson
     Headquarters : C,31th Floor Bilida Building Lvling, Xiamen, Fujian, 361004, China
     Phone : 0086-15980930677, Fax : 0086-592-5594747
     Website : Log on to trade instantly , Email : Log on to trade instantly

     ---- Branch 1 ---
     Contact : Christina
     Address : c 31th floor bilida building lvling, Xiamen, Fujian, 361009, China
     Phone : 86-15980930677, Fax : 86-592-5594747

     Formwork timber beam Formwork timber beam Ubest

For construction use. Carry film faced plywood or other types shuttering panels in formwork to cast cement or concrete. Made of high-grade solid sawn Pine lumber. Prefabricated wood H 20 Beams are manufactured in a range of sizes. Long length adopt fingerjoint to splice flanges and butt jointing or toothed, tongue and groove or scarf configurations to splice the webs. Ubest H20 beam Available Length: (in CM) 180 – 190 – 245 – 250 – 290 – 330 360 – 390 – 420 – 450 – 490 – 590 Weight per running meter: 5.0kgs Bending moment – max.5 kN.m Cutting action – max.11.0 kN Bending – max.1/500 Live load (Bending Stiffness) – max.500 kN/m2
  > Add to cart


     3 layer shuttering panel 3 layer shuttering panel UBEST

Ubest Three Ply Shuttering Panel For construction use, the function of the 3 ply shuttering panel is the same as film faced plywood, in various countries, constructions adopt alternative film faced plywood, shuttering plywood, or 3 ply shuttering panels. Three Ply Shuttering Panels are made of 3-plywood with a thickness of 9 mm each ply. Size: 970 x 500 mm, 1000 x 500 mm, 1500 x 500 mm, 1970 x 500 mm, 2000 x 250 mm, 2000 x 300 mm, 2000 x 500 mm,2000 x 1000 mm, 2500 x 500 mm, 3000 x 500 mm, 4000 x 500 mm, 6000 x 500 mm The 1st and the 3rd ply grain are arranged at right angles to the second ply. Glueing is made with high temperatures and pressure. The moisture content is less than 13%. Both sides of the panels have a melanimic protection in light yellow colour and alkaline proof and to avoid humidity. Thickness: 21mm (3 x 7mm),27mm (3 x 9mm). Glue: WBP (MUF) / E1. Material: Fir/Abisia. Sanding: Double faced sanded and Coated.
  > Add to cart


     3 ply shuttering panel 3 ply shuttering panel Ubest

Ubest three ply shuttering panel: Glue: MUF glue Material: Fir Packing: In Pallet Prepared for Forklift. Thickness: 27mm, 21mm, Width: 500mm Length: 970, 1000, 1500, 1970, 2000, 2500, 3000, 4000, 5000, 6000mm. Tolerance on length and width (mm: -/+3); +/-0.5 Moisture Content: less than 10% Abrasive: less than 0.1g/100r Elasticity: more than 5500Mpa Static Bend: more than 28Mpa Thickness Swelling (72 hours in water): Less than 6% Density: 425kgs/M3
  > Add to cart


     commercial plywood commercial plywood Ubest

Ubest Film Faced Plywood applications formwork farm building sport facilities vehicle walls inside linings bulkheads Bonding: WBP exterior, Coating: Brown phenolic film 120 g/m2 on both sides, alternatively Black 220-240 g/m2 on both sides Edge treatment: Brown acrylic paint or Silver, Purple silicon paint against moisture pick up Thicknesses: 12, 15, 18, and 21 mm Sizes: 1220/1250 x 2440/2500 mm
  > Add to cart


     Film Faced Plywood Film Faced Plywood Ubest

Ubest Film Faced Plywood applications formwork farm building sport facilities vehicle walls inside linings bulkheads Bonding: WBP exterior, Coating: Brown phenolic film 120 g/m2 on both sides, alternatively Black 220-240 g/m2 on both sides Edge treatment: Brown acrylic paint or Silver, Purple silicon paint against moisture pick up Thicknesses: 12, 15, 18, and 21 mm Sizes: 1220/1250 x 2440/2500 mm
  > Add to cart


     H2 Beam H2 Beam Ubest

For construction use. Carry film faced plywood or other types shuttering panels in formwork to cast cement or concrete. Made of high-grade solid sawn Pine lumber. Prefabricated wood H 20 Beams are manufactured in a range of sizes. Long length adopt fingerjoint to splice flanges and butt jointing or toothed, tongue and groove or scarf configurations to splice.
  > Add to cart


     H2 Beam H2 Beam UBEST

Around4.8-5.2kgs per running meter. Treated by Water Proof Glue. (WBP) Prefabricated wood H20 beams are manufactured in a range of sizes. Long lengths use fingerjoining to splice flanges and butt jointing or toothed, tongue and groove or scarf configurations to splice the webs. The actual length is limited only by transportation restrictions Resistant to rough handling and extreme use with longer service life. Weight per running meter: 4.8-5.2k kg Mechanical specification: Bending moment max.5 Kn.m Cutting action max 10.0KN Bending max1/500 Live load max 1.5 KN/m2 Length in cm 180 - 245 - 290 - 330 - 360 - 390 - 450 - 490 - 590
  > Add to cart


     Three ply shuttering panel Three ply shuttering panel Ubest

Ubest three ply shuttering panel: Glue: MUF glue Material: Fir Packing: In Pallet Prepared for Forklift. Thickness: 27mm, 21mm, Width: 500mm Length: 970, 1000, 1500, 1970, 2000, 2500, 3000, 4000, 5000, 6000mm. Tolerance on length and width (mm: -/+3); +/-0.5 Moisture Content: less than 10% Abrasive: less than 0.1g/100r Elasticity: more than 5500Mpa Static Bend: more than 28Mpa Thickness Swelling (72 hours in water): Less than 6% Density: 425kgs/M3
  > Add to cart
